Fox Suspension

MY15-24 F-150

$TBA

RRP. Fitted

DESCRIPTION & INCLUSIONS

The Roush Performance Fox 2.0 Suspension Kit for F-150 4x4 trucks delivers unmatched confidence for both on and off-road performance. This kit has undergone rigorous testing and has earned the distinction of being factory-installed on Roush F-150 trucks from 2015 to 2024. It is thoughtfully designed to perfectly complement the Roush Wheel and Tire Package.


Sourced from the same top-quality manufacturer trusted by Ford for their Raptor trucks, this suspension kit is tailored exclusively for the 2015-2023 F-150 trucks. With comprehensive engineering and testing, it provides your F-150 with a remarkable 2-inch front leveling, resulting in reduced body roll and enhanced stability. This empowers you to drive your truck with the confidence it deserves, whether you're hitting the trails or cruising the streets.


To create a complete system that not only performs exceptionally but also looks fantastic, consider adding the Roush F-150 Fender Flares and Wheel and Tire packages to your setup. The serious off-road performance of this kit has been thoroughly validated by Roush Performance's engineers in both laboratory and real-world testing.


Please note that for 2021-2023 trucks, adjusting the lower spring perch down by 5/8" of an inch on the strut shaft (towards the lower control arm) is necessary for proper suspension travel and improved ride quality.


PRODUCT HIGHLIGHTS

  • Preset with 2.0" of front leveling, (adjustable from 0-2" of leveling). *Ride Height may vary based on truck configuration. Base chassis configurations and engines application will affect finished ride height. Ride height can be adjusted to customer preference using standard coil over spanner wrenches.

  • Nitrogen charged aluminum body coilover shocks with tuned performance springs

  • 6061-T6 aluminum rear shocks with internal floating pistons

  • Specific shock valving for F-150 trucks with upgraded wheel and tire combinations

  • Engineering validated for the Roush F-150 truck program

  • Improved stability and off-road performance

  • Made in the USA


INCLUSIONS:

  • 2 Front adjustable coil over shocks with matched coil springs

  • 2 Billet aluminum mounts

  • 2 Rear aluminum body shocks w/ internal floating pistons

  • 2 Fox mud guard/roost guard for added shock protection
